Chemical Ground Electrodes

Chemical Ground Electrodes

Stainless Steel Chemical Ground Electrodes

We provide common sizes, we also can do according to your requests. Please contact us to get to know more information about our products and service.

inquiry
  • Detail
Product Description

Chemical Ground Electrodes is the latest grounding design ,which reduce the resistance with ion release effect . The available material including pure copper , copper clad steel, stainless steel,copper bonded stainless steel and galvanized steel, we offer the competitive chemical grounding rod price.

Chemical Ground Electrodes (10)

Product Parameter

Material

Pure Copper, Copper Clad Steel, Stainless Steel, Copper Bond Stainless Steel, Galvanized Steel

Copper Purity

99.9%

Size

according to customer's requirement

Straightness error

≤1mm/m

Service life

≥30years

Function

Used in grounding system

Available service mode

OEM,ODM

Certificate

ISO9001:2008,CE,SGS

Product Size

Product Name

Model

Size

Material

Environment

Life       years

Pure Copper Chemical Ground Electrodes

SIG-AA15S95

Φ54x1500mm

pure copper pipe

variety

≥50

SIG-AA30S95

Φ54x3000mm

Copper Clad Steel Chemical Ground Electrodes

SIG-AB15S95

Φ50x1500mm

copper clad steel pipe

variety

≥30

SIG-AB30S95

Φ50x3000mm

Stainless Steel Chemical Ground Electrodes

SIG-AC15S95

Φ51 x1500mm

stainless steel pipe

variety

≥30

SIG-AC30S95

Φ51x3000mm

Copper Bond Stainless Steel Chemical Ground Electrodes

SIG-AD15S95

Φ51 x1500mm

copper bond  Stainless steel pipe

variety

≥30

SIG-AD30S95

Φ51x3000mm

Galvanized Steel Chemical Ground Electrodes

SIG-AE15S95

Φ57x1500mm

galvanized steel pipe

variety

≥30

SIG-AE30S95

Φ57x3000mm

Launch Ring Pure Copper Chemical Ground Electrodes

SIG-AAX15

Φ50x1500mm

T2 copper pipe

bare copper stranded wire

≥50

SIG-AAX30

Φ50x3000mm

SIG-AAX15

Φ60x1500mm

≥50

SIG-AAX30

Φ60x3000mm

Launch Ring Stainless Steel Chemical Ground Electrodes

SIG-ACX15

Φ51 x1500mm

304 stainless steel pipe

stainless steel stranded wire

≥50

SIG-ACX30

Φ51x3000mm

SIG-ACX15

Φ55x1500mm

≥50

Above is the common size, we also can do according to your requests. Please contact us to get to know more information about our products and service.

Product Advantages

Effective resistance reducing : The resistance reducing agent absorb the water from soil to reduce the resistance and keep stable ;

Stable resistance reducing result: The electrolytic ion grounding rod act one week later after installation ,and little effected by the temperature and humidity ,the life can be 30 years ;

Good anti corrosion and conductivity: Good anti-corrosion and conductivity obtained with Skin-effect and pure copper material;

No maintenance cost: No special care after installation ,and the maintenance cost is very low ;

Shiny surface: Experienced workman make the rods with advanced machines ,and the surface is more shiny;

Simple installation: Simple installation both by machine and hand are ok ,and the installation cost is very economical;

Long life: Max copper thickness at single side can reach 0.5mm and theoretical life can reach 30 years ;

Quality accessories: The accessories of rod are made with quality material and 8 years.

Product Application

Chemical Ground Electrodes is used for grounding system of power plant ,transformer station ,tower ,communication station ,airport, railway, subway station , high building ,computer room ,petro plant ,oil reservoir in the environmental of moist ,saline and alkaline ,acid and chemical corrosion medium environmental.

Product Installation

1).Drilling: Dill the hole about 140mm×3500mm on the earth , or dig the channel about 300mmx3500x800mm and install the grounding rod . Multi grounding rods should be connected by the channel 350mmx600mm .

2).Install the ion grounding rod and connect lead wire Remove the seal tape of water absorbing hole and releasing hole (Must );Put the electrode into assy hole ;Connect the lead wire with anti-corrosion bolt and welded with exothermic welding;

If grounding grid is needed with multi grounding electrodes , 95mm2 copper stranded wire or galvanized round wire or galvanized tape is recommended to connected with exothermic welding

3).Fix bentonite and water and fill Fix bentonite and water with the ratio 1:1 Fill the bentonite and about 50mm higher than electrode , and stir with stick to exhaust the air ;Check the connect the refill the soil ,no stone ,stick or plastic piece left.

4).Test the resistance : Test the resistance 3 days later after installation , and retest one month later and six month later to observe the change.

Product Packing

All of our products are with strong packing and free of charge, we also can provide packing according to customer’s requirement.

Chemical Ground Electrodes (9)

About Balic

Shaoxing Bailijia Electric Co., Ltd always concentrate on electric ground products and electric anti-corrosion products’s studying, developing, processing and marketing.

We have got the certification of ISO9001: 2008, and study foreigner’s advanced technology and manage experience. We produce the goods according to the American UL safety standard and European SGS Quality Test standard, our goods are exported to more then 20 countries such as American, England, Vietnam, Egypt, Argentina, Australia and so on, we get very good reputation.

At present, Bailijia Co., produce copper earth rod, exothermic welding flux, electrolytic ion earth rod, physical agent of reducing resistance, copper clad steel strand wire and so on, and have more then thousand sizes, our goods are used on petrification, electric, war industry, communication, railway, weather and so on. As one of our main goods copper earth rod, we export more then 100 containers, we will enlarge our producing size, and waiting for cooperating with you in long time.
